Specification

Item No.	Output torque	Rate speed	Maximum number of output shaft revolutions	Maximum weight of the door leaf.	Voltage	Power	Gearbox Ratio	Protection class	Maximum time of continuous operation
IN-I	35N.m	31RPM	17 revolutiongs	180KG	AC110V-AC220V/50Hz-60Hz	750W	48:1	IP65	10 min
IN-II	50N.m	24RPM	17 revolutiongs	260KG	AC110V-AC220V/50Hz-60Hz	670W	58:1	IP65	10 min
IN-III	50N.m	24RPM	17 revolutiongs	260KG	AC110V-AC220V/50Hz-60Hz	610W	58:1	IP65	15 min
IN-IV	100N.m	24RPM	17 revolutiongs	500KG	AC380V/50Hz	1000W	58:1	IP65	15 min
IN-V	130N.m	18RPM	17 revolutiongs	650KG	AC380V/50Hz	1000W	80:1	IP65	15 min

Features

This door opener is used for big workplant or warehouse.
Advanced design of limited switch adjusting for accurate adjustment.
Lower noise, high IP class.
Easy installation. In case of power failure, the gate can be opened and closed manually after release clutch.
The door opener is equipped with an overheat protection device.
Door opening machine with advanced grease, maintenance free.

Advantages

Multiple models can be selected to adapt to different voltages.
The amount of weight that can be carried varies.
High level of protection, not easy to damage, can adapt to different pressure conditions.
New appearance, compared with the original more beautiful and atmospheric.
Automated devices called industrial door openers are used to regulate the opening and closing of doors in areas where people arrive and depart. Numerous locations, such as offices, malls, schools, hospitals, hotels, factories, etc., make extensive use of them.

Home application scenarios

Simply push the button on the door opener to verify the visitor's identity and speak to him via sound or picture when he knocks.

Business domain

Door openers are typically used by access control systems in retail centers, office buildings, hotels, etc. to guarantee the security and ease of entry and exit.

Public areas

Such as airports, schools, hospitals, and other places where a lot of people come and go each day. Door openers are now necessary pieces of equipment to maintain safety and order.

Typical Kinds

Hinged type

Installed on the door's hinge, the hinged kind is appropriate for doors that receive a lot of traffic.

Buried type

Placed beneath the door body's hinge, it won't harm either the door or the environment. At the moment, it is the most popular door opener.

Push rod type

Push rods are wall-mounted installations that come in hydraulic and electromechanical varieties. They are appropriate for doors that open and close quite frequently.

Wheel type

Appropriate for standard courtyard doors, mounted at the bottom of the center of the door body, running toward the ground.
Installed at the top beam of the door body, this type of door closer is appropriate for frequent opening and is installed similarly to other door closers.
